Gecko IN.YE-3-V2 Control Box with 3KW Heater

Gecko IN.YE-3-V2 Control Box with 3kW Heater

The Gecko IN.YE-3-V2 control box is a compact, high-performance spa control system built for versatility, reliability, and ease of installation. Suitable for both entry-level hot tubs and advanced swim spas, it supports up to 3 pumps and features a powerful 3kW heater, integrated temperature probe, and IPX5-rated waterproof casing.

Key Features:

• Supports 1, 2 or 3 pumps

• Includes 3kW, 2” x 15” flow-through heater with built-in temperature probe

• IPX5 waterproof rated design

• Solid-state flow detection – no pressure switch needed

• Self-diagnostic system with overheat and freeze protection

• Programmable filter cycles

• 12V AC light support

• 3 configurable relays

• Compatible with in.touch Wi-Fi module for smart control https://www.wizardhottubs.co.uk/product/gecko-in-k1001-topside-control/

• Corrosion-resistant enclosure

• Connector type: AMP with quick-connect; JJM adaptor available

• System Specs at a Glance:

  • Heater: 3kW

  • Pump Support: Up to 3 pumps

  • Circulation Pump: Yes

  • Blower: No

  • Ozone: Yes

  • Lights: Yes

  • Wi-Fi: Optional (via in.touch module)

  • Audio: Not supported

This unit must be fitted by a competent individual or tradesman. Incorrect installation could invalidate the warranty.
